Purpose-built for EV charging
Specifications below are example market references checked against publicly available manufacturer pages and English datasheets. Use them to shortlist, not to release a drawing.
Four-pole AC charging relay with weld-detection auxiliary contact for Mode 3 charge points and wallboxes in UAE EV programmes.
Two-pole charging relay fully compliant with the IEC 62955 10 kA short-circuit and 500 A switching tests for single-phase AC chargers.
Final parameters, derating and ordering codes are always governed by the manufacturer’s latest datasheet for the exact version selected.
The model family narrows the search. The exact ordering code follows only after the load, voltage, coil, environment, standards and volume are known.
Resistive, inductive, motor, lamp, capacitor or DC fault duty
Working voltage, continuous current, inrush and switching frequency
Coil supply, tolerance, suppression and auxiliary feedback
Enclosure temperature, altitude, vibration, sealing and duty cycle
Use the manufacturer page (third-party) for current datasheets, certificates, ordering codes and engineering confirmation.
Manufacturer product page (third-party)Share the operating conditions and intended annual volume. No local availability or approval is assumed.
